Features of capability and structure:
1. One truck can carry several garbage bins. Therefore the transportation efficiency can be increased and transportation charge can be decreased.
2. There is no the second pollution during transporting. It only takes very small area so it saves the ground. And it does not need to be equipped with additional lifting equipment.
3. It adopts extraordinary high strength wearable steel with the bend intensity of 490N/mm;
4. The equipment has a small weight and high lifting capacity and its Max. self-discharging incline angle is 51.
5.  The equipment safety system including: Transshipment retaining valve, hydraulic and incline locking device, mechanical locking device.
6. The advanced support outrigger for loading and unloading heavy bins makes it work well both on hard ground and soft ground.
